Empulse (Sunrise Medical) · Rear push-assist devices · PA-010
Empulse R20 attendant wheelchair power pack
The Empulse R20 is an attendant wheelchair power pack from Sunrise Medical that helps a carer push. It weighs 9.9 lb with its lithium-ion battery, folds, and docks to the chair without tools. A 250 W motor offers three speeds of 1.2, 2.3 and 3.1 mph, and a free-run mode lets the user self-propel with the unit still fitted.
- Type
- attendant power pack
- Weight
- 9.9 lb with battery
- Max user weight
- 375 lb
- Max total weight
- 419 lb, wheelchair plus user
Empulse R20 key features
- Click-fix docking with no tools
- Three speed levels: 1.2, 2.3 and 3.1 mph
- Free-run mode for self-propelling
- One-button on and off, adjustable control unit
- Folds and travels in a supplied backpack
- 36 V lithium-ion battery of 209 to 216 Wh
Who the Empulse R20 suits
For carers and attendant-pushed users with folding or tilt-in-space manual chairs, especially on slopes of up to 10 degrees. The chair needs a box frame with tubing of 22 to 28 mm.
Figures for comparing
- Weight
- 4.5 kg (9.9 lb)
- Max user weight
- 170.1 kg (375 lb). 375 lb user; 419 lb max total wheelchair plus user
- Range
- 14 km (9 miles)
- Top speed
- 5 km/h (3.1 mph)
The same units on every product, converted from the specifications below. Where a source gives two limits, the lower one is shown.
Empulse R20 specifications
| Type | attendant power pack |
|---|---|
| Weight | 9.9 lb with battery |
| Max user weight | 375 lb |
| Max total weight | 419 lb, wheelchair plus user |
| Top speed | 3.1 mph, three settings |
| Range | up to 9 miles |
| Motor | 250 W |
| Battery | lithium-ion, 36 V, 5.8 to 6 Ah |
| Seat widths | 13 to 23 in |
| Compatibility | box frame, tube diameter 22 to 28 mm |
| Max slope | 10 degrees |
| Maker country | Germany/USA |
| Brand | Empulse (Sunrise Medical) |
| Category | Power add-ons for manual wheelchairs, Rear push-assist devices |
| Catalog ID | PA-010 |
Compared with the source page on 5 October 2026. Details can change, so we confirm them in your quote. Open the source page.
Empulse R20: common questions
Which wheelchairs does the Empulse R20 fit?
Most folding and tilt-in-space manual chairs with a box frame and tubing of 22 to 28 mm, in seat widths from 13 to 23 in.
Can the user still self-propel with the R20 attached?
Yes. A free-run mode lets the wheels turn freely so the user can push the handrims.
How much weight can the Empulse R20 move?
It is rated for a user of up to 375 lb and a combined wheelchair and user weight of 419 lb.
How to get a quote for the Empulse R20
Add it to your enquiry list
Press Add to enquiry. You can add other products and parts to the same list.
Tell us your country and needs
Send the list with your country, sizes and any options you want. No payment details are asked.
Get a personal reply
You receive availability, a price and delivery options by email, and decide after that.
