Karman Healthcare

Karman KM-5000 aluminium reclining wheelchair

Photo: dealer listing. Rights belong to the maker.

Karman Healthcare · Reclining · MW-053

Karman Healthcare KM-5000

KM-5000 reclining wheelchair

Maker no. KM5000F18B-MS, KM5000F16B-MS, KM5000F20B-MS, KM5000F22B-MS, KM5000F-TP, KM5000F-TP-16 and 2 more · Also sold as KM-5000F

Product details checked:

The Karman KM-5000 is a folding reclining wheelchair with a 6061-T6 aluminium frame that weighs 36 to 38 lb without footrests. Its 33 inch back lowers from upright at 90 degrees to 163 degrees, and swing-away elevating legrests raise the legs to match. A height-adjustable head pillow and anti-tippers are part of the standard chair.

You can order the Karman Healthcare KM-5000 through Mobility Atlas with delivery to Australia, New Zealand, the Gulf, Southeast Asia, Israel, Latin America, the United States and most other countries. Send an enquiry with your country, and Anna replies within 24 hours with a written quote. Our price is US$1,541 before delivery.

Chair weight
36-38 lb without riggings
Max user weight
250 / 300 / 350 lb
Seat widths
16 / 18 / 20 / 22 in
Seat depth
17 or 18 in

Key features

  • Backrest reclines from 90 to 163 degrees
  • Folding 6061-T6 aluminium frame in black powder coat
  • Seat widths of 16, 18, 20 or 22 inches
  • Capacity of 250, 300 or 350 lb depending on configuration
  • 24 inch mag wheels with flat-free polyurethane tyres
  • Detachable full-length padded armrests

Who it suits

For people who need to lie back during the day, for example those managing pressure sores or back pain, and for carers who want a recliner light enough to fold and lift. Choice of recliner and cushion for pressure care should involve a clinician.

Figures for comparing

Seat width
40.6 to 55.9 cm (16.0 to 22.0 in)

The same units on every product, converted from the specifications below. Where a source gives two limits, the lower one is shown.

Part numbers and names

Model numbers
KM5000F18B-MS (version KM5000F18B-MS as listed in the UPC table); KM5000F16B-MS (version KM5000F16B-MS as listed in the UPC table); KM5000F20B-MS (version KM5000F20B-MS as listed in the UPC table); KM5000F22B-MS (version KM5000F22B-MS as listed in the UPC table); KM5000F-TP (version KM5000F-TP as listed in the UPC table); KM5000F-TP-16 (version KM5000F-TP-16 as listed in the UPC table); KM5000F-TP-20W (version KM5000F-TP-20W as listed in the UPC table); KM5000F-TP-22W (version KM5000F-TP-22W as listed in the UPC table)
Barcode (GTIN / EAN / UPC)
661799289856 (UPC, item KM5000F18B-MS); 661799289849 (UPC, item KM5000F16B-MS); 661799289832 (UPC, item KM5000F20B-MS); 661799289825 (UPC, item KM5000F22B-MS); 045635099784 (UPC, item KM5000F-TP); 045635099791 (UPC, item KM5000F-TP-16); 045635099807 (UPC, item KM5000F-TP-20W); 045635099814 (UPC, item KM5000F-TP-22W)
HCPCS code (US)
E0966, E1226, K0004
Also listed as
KM-5000F

As printed by the maker or the seller on 13 November 2026. Send us the number from your quote or the product label and we match it before we buy.

Documents

  • KM-5000F Product Literature (brochure, uploaded 2013/01)
  • KM-5000 Product Manual (owner's manual, uploaded 2013/01)
  • KM5000 Reclining Wheelchair Series Order Form (msrp) (order form, uploaded 2013/01)

Published by the maker or the seller, seen on 13 November 2026. Ask for them with your enquiry and we send them with the quote.

Specifications

Chair weight36-38 lb without riggings
Max user weight250 / 300 / 350 lb
Seat widths16 / 18 / 20 / 22 in
Seat depth17 or 18 in
Seat height20 in
Back height33 in
Back recline90° to 163°
Overall width25 / 27 / 29 / 31 in
Frame6061-T6 aluminium, folding
Wheels24 in mag rear, 8 x 1 in front casters
Brand countryUSA
BrandKarman Healthcare
CategoryPositioning & special-function, Reclining
Catalog IDMW-053

Compared with the source page; product details last checked on 13 November 2026. Details can change, so we confirm them in your quote.

Ordering: seller, delivery, payment

Seller
PulsCar, LLC, the US company that runs Mobility Atlas (800 N King Street, Suite 304-3245, Wilmington, DE 19801, USA). Anna, the founder, handles every order herself.
Reply
A written quote within 24 hours of your enquiry.
Price
US$1,541. The price covers finding the product, buying it and arranging export. Delivery to your country is added in the written quote.
Availability
Sourced to order. Nothing is held in stock: we buy it from the maker or a dealer once you accept the quote.
Delivery
Arranged to most countries, including Australia, New Zealand, the United Arab Emirates, Saudi Arabia, Qatar, Kuwait, Bahrain, Oman, Singapore, Malaysia, Hong Kong, the Philippines, Israel, Mexico, Brazil, Colombia, Chile, Peru, Argentina and the United States, from about US$350 for an item like this. As a rough guide, items in stock at a US or European supplier usually arrive in one to three weeks, and chairs built to order in four to ten weeks. The quote states the exact delivery cost and time, and whether import duties and taxes are included.
Payment
Only after you accept the written quote: by card through a secure payment link, or by bank transfer.
Cancellation
Full refund until the product has been bought for you.
Warranty
Warranty terms are confirmed in your quote. We handle warranty claims with the maker or dealer.

Delivery, payment and returns in full · How ordering works

What to send with your enquiry

  • Your country, so the quote includes delivery.
  • The size and options you need. For a chair made to measure, send your measurements; the page on how ordering works lists them.
  • Any deadline. We tell you the lead time before you pay.

Common questions

How much does the Karman KM-5000 weigh?

It weighs 36 to 38 lb without the legrests fitted. The shipping weight is 60 lb.

How far back does this wheelchair recline?

The backrest moves from 90 degrees upright to 163 degrees, close to lying flat.

What does this wheelchair cost?

Our price is US$1,541 before delivery, set on 28 October 2026; the written quote adds delivery and any import duties.

Can I buy this wheelchair in my country?

Yes. Mobility Atlas delivers it to Australia, New Zealand, the Gulf, Southeast Asia, Israel, Latin America, the United States and most other countries; our price is US$1,541 before delivery, and Anna sends a written quote with delivery to your country within 24 hours. As a rough guide, items in stock at a US or European supplier usually arrive in one to three weeks, and chairs built to order in four to ten weeks. Delivery for an item like this starts at about US$350; the Ordering section on this page has the details on cost, payment and cancellation.

Who sells this wheelchair?

PulsCar, LLC, the US company that runs Mobility Atlas, buys it from the maker or a dealer and resells it to you. Anna, the founder, handles every order herself. Mobility Atlas is an independent buying service, not an official Karman Healthcare dealer.

Can I cancel after I order?

Yes, with a full refund, until the product has been bought for you. Payment is taken only after you accept the written quote.
